69kV AC Voltage Detector

SKU: MT269

  • Bright LED visual indication
  • Audible indication
  • AC voltage detection: 100V AC to 69kV AC
  • Non-contact detection by proximity
  • Convenient to use neck hanging strap and case
  • On/Off switch Self-test function
  • Comply with EN 61326-1
  • Lightweight, robust and compact

R 3 570.00 ex. VAT R 4 105.50 in. VAT

Details

The MT269 is a lightweight robust wearable proximity sensor for detecting AC High Voltage up to 69kV. It provides electrical personnel, firefighting personnel, and instrument technicians with a bright visual dual LED indication and audible warning of up to 99dB when approaching any high voltage source above 110V. The MT269 is also equipped with a self- test function to ensure the unit is in working condition. The unit comes with a metal belt clip and carrying case.

Specifications:

Function Range
Non-Contact Voltage (NCV) Yes
AC Voltage 100V – 69kV AC
Frequency 40 – 70 HZ
Voltage Detector Visual 2 x Hi bright red LED
Voltage Detector Audible Continuous beep
Enclosure Moulded
Battery 9V
Weight 153g
Dimensions 110 x 71 x 40mm
Safety Specs IEC61326-1

Accessories:

  • Carrying Case
  • 9V Battery
  • Instruction Manual
