Digital 10A Micro-ohm Meter

SKU: MT986

4-Wire test method
10A constant current
Resistance range 0.001mΩ to 6kΩ
Temperature Measurement: -5°C to 50°C
Wire Length Measurement up to 30,000m
Data storage of 999 sets
Time and Date display
4.0 Bluetooth
Bluetooth function allows connection to Android and iOS mobile phones

Quantity

R 11 830.00 ex. VAT R 13 604.50 in. VAT

Add to Cart

Add to wishlist

Details

The MT986 is a 10A Micro-Ohmmeter, also known as transformer DC low resistance tester through the 4-wire method. Features include resistance from 0.001mΩ to 6kΩ with time and date, comparison function to determine if the device is in good condition, unknown wire cable length calculation, Temperature measurement, built-in Bluetooth interface and a 2600mAh rechargeable lithium battery. The MT986 can be used in narrow space troubleshooting, such as metal coating resistance/motor and small transformer winding resistance measurement, earth system joints, welding points and power distribution cabinet bus and lead connection inspections. The meter has a rechargeable Lithium battery, eliminating the need to find electricity on site. Large LCD display, easy to see at a glance and stores up to 999 sets of data. Stored data can be transferred through the Meter-X app to Android or iOS devices.

Specifications:

Function	Range
Contant Current	10A
Resistance	0.001mΩ to 6kΩ
Cable Length Measurement	0.1m to 30 000m
Temperature	-5°C to 50°C
Detection Method	4-Wire test
Data Storage	999 sets
Display	99999 Count
Bluetooth	4.0
Ingress Protection	IP65 Dust & Waterproof
Auto Power Off	After approx. 15 minutes (can be disabled)
Battery	7.4V Lithium Rechargeable Battery (2600mAH)
Dimensions	212 x 100 x 67mm
Weight	600g
