MS363
Infrared Motion Sensor
R258.75
Features :
- 180° Detection Field
- Detects body movement
- Easy Installation
- Adjustable setting for time and lux
- 800 Watts Incandescent lamps or 400 watts energy saving lamps
- 180° wide angle sensor
- 3, 30, 300, 2000 LUX (selectable)
Description
The PIR34 is designed to automatically turn lights on when motion and body heat is detected. The sensor has a 180° detection range with adjustable time and light level, and can be connected to existing lighting installations. The sensor can be installed inside or outside under eaves.
Application:
Major Tech Infrared Motion Sensor is ideal for home use and also in educational and commercial properties.
Downloads
Additional information
| Detection Angle | 180° |
|---|---|
| Detection Range | 12m |
| Detection Type | PIR |
| Installation Height | 1.8m to 2.5m |
| No. PIR Detectors | 1 Detector |
| Protection Grade | IP44 |
| Rated Load Energy Save | Max: 400 Watts |
| Rated Load Incandescent | Min: 800 Watts |
| Time Delay | 10s, 30s, 90s, 3m, 7m & 15m (2± min) |
| Working Voltage | AC220 – 240V |
